Blender, Maya, and GPU/CPU rendering from HD viewports to 4K final frames.
Overview
3D and VFX workloads are scene-complexity driven: polygon count, textures, simulations, and render engine choice matter more than monitor size alone. GPU renderers (Cycles GPU, Redshift, Octane, V-Ray GPU) need VRAM and CUDA/OptiX or HIP support; CPU fallbacks and physics still want cores. Resolution tabs reflect typical final output / viewport target — 4K frames and heavy AOVs need high-end GPUs and 64 GB RAM.
Choose 1080p, 1440p, or 4K to match your timeline, export, or render target, then pick project complexity (Basic through Professional). Minimum specs handle the workload with compromises; recommended adds headroom. At Professional, an optional NVIDIA RTX Pro (formerly Quadro) workstation row appears below the GeForce / RX graphics card.
1080p · Standard project
Standard 3D scene — 1080p final frames / HD viewport, standard geometry and materials
GPU- and RAM-heavy estimates for viewport and final-frame rendering at 1080p with a standard project profile. Minimum handles typical jobs with patience; recommended adds headroom for tight deadlines.
Graphics card
Minimum
RTX 3060 12 GB / RX 6700 XT 12 GB
Recommended
RTX 4060 Ti 16 GB / RX 7700 XT 12 GB
Viewport and GPU render engines (Cycles, Redshift, Octane) need VRAM for textures.
Processor
Minimum
Ryzen 5 5600 / Intel Core i5-12400
Recommended
Ryzen 7 5800X / Intel Core i7-12700
CPU rendering and physics sims still scale with core count and clock.
Memory
Minimum
32 GB (dual-channel)
Recommended
32 GB (dual-channel)
Scene complexity—not display resolution—often drives RAM needs first.
Storage
Minimum
1 TB NVMe SSD
Recommended
2 TB NVMe SSD
Cache and bake files can fill drives quickly on animation projects.
Workflow tips
· Use GPU rendering when your engine supports it; fall back to CPU buckets for very large scenes only when needed.
· Keep texture and simulation caches on NVMe — network drives stall viewport updates.
· Viewport resolution can stay below final render — do not size GPU only by monitor pixels.
Performance notes
· Viewport smoothness depends on GPU and driver — final-frame GPU rendering depends on VRAM and shader complexity.
· 64 GB system RAM is common for animation, fluid sims, and large environments; 32 GB is a realistic minimum for solo artists at 1080p output.
· NVIDIA cards dominate GPU render plugin support; Redshift and Octane are CUDA-only — AMD RX is for Blender HIP, not those engines.
· Unreal and real-time archviz prioritize GPU and fast storage over CPU core count compared to offline path tracing.
· Professional tier lists NVIDIA RTX Pro (RTX 4000–6000 Ada, formerly Quadro) where 32–48 GB VRAM and ISV drivers matter more than GeForce gaming value.
What affects performance
GPU / VRAM
Textures, geometry, and render tiles live in VRAM — out-of-memory errors force CPU fallback or failed frames.
RAM
Simulations, caches, and high-poly scenes use system memory independent of GPU VRAM.
CPU
Physics, baking, and CPU render buckets still scale with cores when GPU paths are unavailable or hybrid rendering is used.
